indoor LED display EKTA iLVM4c-qc

Module type: EKTA iLVM 4C-Qс

Pixel pitch: 4.83 mm

Environments: Indoor

LED arrangement: 3 IN 1 SMD

Module resolution: 80 × 80 pixels

Module dimensions: 386.4 × 386.4 × 85 mm

Module weight: 4.2 kg

Maximum brightness: 2,500 nits

Calibrated brightness: 2,000 nits

Viewing angle: 145° / 125°

Display color: up to 18,000 trillion (54 bit)

Greyscale: 18 bit

Power consumption:

average 330 W/m², maximum 1,000 W/m²,

calibrated mode 820 W/m²

Operating power source:

110–253V; 50–60Hz

400V +10%/–20%; 50–60Hz

Control system: EKTA ERMAC

Refresh rate: 7,200 Hz

Scan rate: 1/10

Operating temperature: from +1 °C to +40 °C

Operating humidity: 80%

‍

The EKTA iLVM 4C-Qс is a high-precision indoor LED display module engineered for professional installations that require exceptional image stability, long-term reliability, and consistent colour performance. With EKTA’s advanced electronics and precise calibration, the module delivers smooth visuals, wide viewing angles, and excellent uniformity across the entire display surface.

Why it’s ideal for TV studios and broadcast

• 18-bit colour processing ensures ultra-smooth gradients, accurate skin tones, and high dynamic tonal precision.
• EKTA ERMAC control system guarantees stable grayscale performance, deep colour depth, and perfectly matched brightness across all modules.
• High 7,200 Hz refresh rate delivers flicker-free performance on professional broadcast cameras, eliminating scan lines and moiré effects.

This combination makes the iLVM 4C-Qс an excellent choice for TV studios, XR environments, corporate stages, and premium indoor LED installations where superior image quality is essential.
